Wagner 0180/0183 Navigational Interface Control Head Package (New, Old Stock)

Be the first to review this product

Availability: Out of stock

Regular Price: $500.00

Special Price $350.00

Quick Overview

WAGNER Original Item!


Nav I/F Option for Wagner MK4, SE 2 & S50 Autopilots ONLY!


HOLIDAY Special

Wagner 0180/0183 Nav IF Control Head Pkg

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

  • Wagner 0180/0183 Nav IF Control Head Pkg

Details

Operation is as Simple as Turning the Unit ON, and Adjust the Gain Control until satisfactory Steering Response is Achieved.

Once ON the NAV IF Intercepts the Compass Signal & Compares it with the Heading calculated by the NAV Receiver. It then SENDS the Necessary Steering Control Signals to the Autopilot.

When NAV IF is Turned OFF the Autopilot Operates NORMALLY!

Features:

  • Visual & Audible Alarms
  • Two (2) NAV Reciever Input Channels
  • NMEA 0183, 0182, 0180 and Sitex Communication Formats
  • Turn Rate Limit Adjustment
  • Multiple WAYPOINTs Supported with User 'Accept" Switch
  • Magnetic Bow & 1:1 Gyro Compass Supported (For MK4 Gyro Version)

Includes Mountng Bracket, Control & Compass Cables to Hook-Up to Wagner Control Head & Compass Cable w/Plug for Hook-Up to Magnetic Compass Sensor. Customer Supplied Nav Receivers Connect via 2 BNC Plugs on Rear of Case.



Additional Information

Name Wagner 0180/0183 Navigational Interface Control Head Package (New, Old Stock)
Manufacturer Wagner
SKU 510-443
Weight 5.0000
Condition New (Old Stock)
Shipping Time 1 BIZ Day After Payment ... Ships From Boston
Exchange Credit No
Special Price To Date Dec 31, 2018
Manufacturer's Suggested Retail Price $695.00
